• All-aluminum titanium alloy cover and the support plate, high strength, good toughness, lightweight.
• Digital display integrated display, easy to adjust.
• High detection accuracy ±1.5%.
• One detector can replace the square inserts, suitable for a wide range of wrenches.
• The pivot point of the reaction arm can be adjusted 360°, and different types of wrenches can be stably supported.
Model | Torque detection range(Nm) | Detection precision | Input power | Input square drive | Dimension (mm) | Weight (Kgs) |
TC-05 | 500-5000 | ±1.5% | 220V/50Hz | 1” | 340*230*170 | 19 |
TC-10 | 1000-10000 | 1-½” | 480*290*215 | 52 | ||
TC-20 | 2000-20000 | 2- ½” | 480*290*260 | 70 | ||
TC-30 | 3000-30000 | 2-½” | 480*300*300 | 85 | ||
TC-60 | 6000-60000 | 2-½” | 610*330*300 | 198 |
